Copper Tubing for HVAC/R Applications
Designed for compatible air-conditioning, heat-pump, mini-split, and refrigeration installations requiring insulated copper tubing.
ARMBRIDGEAccessories
ARMBRIDGE K-Flex Insulation w/ Plain Ends
Made for your comfort project. Explore the details below.
$156.00
Configure your system
Model: AB-1/4LS-1/2PE-50 (1/4"x50' K-Flex 1/2" Insulation w/ Plain Ends)
Limited warrantyView coverage
Free shippingEligible orders $300+
System selectionQuotes, product details & orders
What's included
Your equipment, clearly laid out.
Confirm installation-kit contents, line lengths and mounting requirements before ordering.
Every $1,500.00 in your cart after discounts earns up to $100.00 off one eligible Armbridge accessory.
Offer stacks: $1,500 earns one eligible accessory; $3,000 earns two; and so on. Eligible Armbridge items include brackets, ground stands, condenser pads, rubber feet, disconnect boxes, A/C whips, and decorative line-set covers. Refrigerant line sets and installation kits are excluded from accessory savings.
Explore the accessory offer →Complete your installation
Accessories paired with this equipment. Choose the options your installation needs.
Product description
Armbridge • Insulated Copper Refrigeration Tubing
Armbridge Plain-End Insulated Copper Tubing with 1/2" Insulation
Individually insulated copper tubing for compatible mini-split, heat-pump, air-conditioning, and refrigeration installations. Choose the required tube diameter and roll length.
5 Tube Sizes
1/4" through 3/4"
50' or 164'
Available roll lengths
1/2" Insulation
Insulation thickness
Plain Ends
Ready for field preparation
Multiple sizes in one listing
Select the copper-tube diameter and roll length required for your job
Armbridge insulated copper refrigeration tubing is available in multiple outside diameters and two roll lengths. Each tube is covered with 1/2-inch insulation to help reduce heat transfer and moisture condensation during normal HVAC and refrigeration operation.
The tubing is supplied with plain ends, allowing the installer to cut, prepare, flare, braze, or connect the tubing according to the equipment manufacturer's requirements.
Individual copper tube
1/2-inch insulation
50-foot rolls
164-foot rolls
Plain ends
Protective end caps
Factory-Applied Insulation
Each copper tube is covered with 1/2-inch insulation to help limit heat transfer and reduce condensation along the refrigerant line.
Made for Indoor and Outdoor Runs
The insulation is designed to resist ultraviolet exposure, tearing, moisture, and normal conditions found in HVAC installations.
Plain Ends for Field Preparation
Plain copper ends give installers the flexibility to prepare the tubing for the connection method required by the selected equipment.
Protected During Storage and Handling
Plastic end caps help keep dirt and debris out of the copper tubing before it is cut and connected.
Two Roll Lengths Available
Choose a 50-foot roll for shorter installations or a 164-foot roll when longer runs or multiple cuts are required.
Available Variations
| SKU | Copper Tube O.D. | Insulation Thickness | Roll Length | End Type |
|---|---|---|---|---|
| AB-1/4LS-1/2PE-50 | 1/4 in. | 1/2 in. | 50 ft. | Plain ends |
| AB-3/8LS-1/2PE-50 | 3/8 in. | 1/2 in. | 50 ft. | Plain ends |
| AB-1/2LS-1/2PE-50 | 1/2 in. | 1/2 in. | 50 ft. | Plain ends |
| AB-5/8LS-1/2PE-50 | 5/8 in. | 1/2 in. | 50 ft. | Plain ends |
| AB-3/4LS-1/2PE-50 | 3/4 in. | 1/2 in. | 50 ft. | Plain ends |
| AB-1/4LS-1/2PE-164 | 1/4 in. | 1/2 in. | 164 ft. | Plain ends |
| AB-3/8LS-1/2PE-164 | 3/8 in. | 1/2 in. | 164 ft. | Plain ends |
| AB-1/2LS-1/2PE-164 | 1/2 in. | 1/2 in. | 164 ft. | Plain ends |
| AB-5/8LS-1/2PE-164 | 5/8 in. | 1/2 in. | 164 ft. | Plain ends |
| AB-3/4LS-1/2PE-164 | 3/4 in. | 1/2 in. | 164 ft. | Plain ends |
Product Specifications
| Specification | Details |
|---|---|
| Brand | Armbridge |
| Product type | Individually insulated copper refrigeration tubing |
| Copper tube sizes | 1/4, 3/8, 1/2, 5/8, and 3/4 in. O.D. |
| Available lengths | 50 ft. and 164 ft. |
| Insulation thickness | 1/2 in. |
| End configuration | Plain ends with protective plastic caps |
| Copper designation | C12200 copper |
| Copper tubing standard | ASTM B280 |
| Insulation temperature range | -40°C to 120°C |
| Pressure rating | Varies by tube diameter; supplied specifications list a range of approximately 2,100 to 7,000 psi |
| Recommended applications | Ductless mini-splits, heat pumps, central air-conditioning systems, and refrigeration equipment |
This listing is for one individually insulated copper tube, not a paired
line set. Select the outside diameter and roll length required for the
installation. Confirm the equipment's specified liquid-line and
suction-line sizes before ordering. Installation should be completed by
a qualified HVAC professional in accordance with the equipment
manufacturer's instructions and applicable codes.
